100W Manual Zoom 15-60degree 3200K/5600K Studio Room Using LED Fresnel Spot Light

FOB Reference Price:Get Latest Price
US $278-300 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Light Source:
LED
LED Light Source:
100w COB led lamp
Type:
Fresnel Lights
Input Voltage(V):
AC90-240V
Lamp Power(W):
150
Lamp Luminous Flux(lm):
7950
Lamp Luminous Efficiency(lm/w):
76890
CRI (Ra>):
95
Color Temperature(CCT):
from warm white to cold white
Working Temperature(℃):
-25 - 45
Working Lifetime(Hour):
50000
IP Rating:
IP33
Certification:
CCC, CE, EMC, LVD, RoHS
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
VanGaa
Model Number:
VG-PB100W
Emitting Color:
Warm White to Cold White
Control mode:
DMX512/master-slave/auto
Product name:
100w led fresnel spot light, 3200K/5600K
Color:
CW/WW
Application:
studio room/stage/TV station
Leds:
100w COB LED lamps
Beam angle:
15-60degree
Zoom methods:
manual zoom/DMX zoom
Dimmer:
0-100% linear dimmer
Illuminance:
2700 Lux (6m 15°)
DMX channels:
1CH, 2CH
Packaging & Delivery
Packaging Details
Carton board package size: 510*320*370mm(1pc/carton)
N.W/G.W/V.W: 5.8kg/7kg/13kg
Port
Guangzhou
Lead Time :
3-15 days based on quantity
Product Description

100W Manual Zoom 15-60degree 3200K/5600K Studio Room Using LED Fresnel Spot Light

brightness 100w led fresnel spot light, light weight, compact body

Product Detail

Light Sources100W COB LED Lamp
Lifespan50000h
ColorCold white, or warm white
Beam angle15-60degree, manual zoom/DMX zoom
Dimmer0-100% linear dimmer
Strobe1-25 times/second
CRIRa≥92
Color temperature3200K/5600K optional
DMX channel2CH
Related voltageAC100V-240V, 50/60Hz
Product Keywords100w, 150w led fresnel spot light which is suitable for concert, theater, studio, tv and other places

Features:

·This television projector light equips high power 100W LED lamps as the light source, it’s energy saving. And it uses high efficiency optical lens, light soft. It’s a best choice for film and television performances, studio and other places.

Features

·The internal adopts full copper radiator large area, good heat dissipation, ensure the lifespan of the LED Lamps;

·Through efficient optical lenses, with special heat dissipation design, make the light is downy, small stray light, no glare, eyes more comfortable;

·Use the LED video projector scheme, the light energy saving 80%;

·Because of almost no infrared radiation, it has greatly improve work environment.

Technical Specifications

Light Sources

·LED: 1pc 100W COB LED Lamps

·Lifespan: 500,000h

·Color: CW, WW optional

Optics

·Beam angle: 15-60degree

·Dimmer: 0-100% linear dimmer

Light Output

·Luminous flux: 3810

·Illuminance: 1800 Lux (6m 15°)

·Optimal projection distance: 15-30m

Control

·Control mode: DMX-512; Auto run

·DMX channel: 1CH, 2CH

·Display of control panel: LCD display + 4 buttons

Power Supply

·Related voltage: AC100V-240V, 50/60Hz

·Related power: 150W

Construction

·Body dimension: D455*W265*H292mm

·Net weight: 5.8kg

·Shell color: black

·Shell material: aluminium die casting

Working Environment

·Working temperature: -25-40℃

·Cooling: Radiator and Fan

·Protection rating: IP20

Standard Configuration Spare Part List

·Cable: 1pc 3-pin DMX cable, 1pc power cable with plug(America standard, Euro standard, or other standard)

·User manual: English version user manual

Optional Configuration Spare Parts List

·Clamps: different style clamps optional (choose from VanGaa homepage “Accessaries series”)

·Safety rope: different size safety ropes optional (choose from VanGaa homepage “Accessaries series”)

Package

·Carton board package size: 510*320*370mm(1pc/carton)

·N.W/G.W/V.W: 5.8kg/7kg/13kg

·Flight case package size: 745*640*650(4pcs/flight case)

·Net weight of flight case: 30kg

·N.W/G.W/V.W: 24kg/54kg/63kg

·Flight case package size: 1100*640*650(6pcs/flight case)

·Net weight of flight case: 34kg

·N.W/G.W/V.W: 36kg/70kg/92kg

Selling Maintain Spare Parts List

·Switching power supply: VG-PB100W-P

·LED lamp board: VG-PB100W-L

·Main board: VG-PB100W-M

·Drive board: VG-PB100W-D

Quality assurance:

1. We equips high quality spare parts for this light, the quality is very good and stable;
2. The light has 1+4 years quality assurance;
3. If you have any quality request, please contact with us freely.

Packaging & Shipping

PACKAGE:

Carton board box package, or flight case package(chargeable).

DELIVERY TIME:

3-15 days after confirming order,detail delivery date should be decided according to
production season and order quantity.

Company Information

ABOUT US

VanGaa Lighting Co., Limited(Guangzhou VanGaa Lighting Technology Co., Ltd) is an internationally recognized company that specializes in energy efficient LED technology for LED Studio Light, we are always focus on the led studio light and stage light technology development and revolution.




FAQ
Q

How can I get the sample to check your quality?

A

After price confirmation, you can require for samples to check our product’s quality. Because this is the professional lighting industry, we don't provide the free samples.

Q

What can I get the price?

A

We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please tell us in your email so that we will regard you inquiry priority.

Q

What is your term of delivery?

A

We accept EXW, FOB Shenzhen or FOB Guangzhou. You can choose the one which is the most convenient or cost effective for you.


Q

What about the lead time for the mass production?

A

Honestly, it depends on the order quantity and the season you place the order.
